Seat Binder
Alloy, 38.6mm
Frame
FACT 11m carbon chassis and rear-end, asymmetrical design, 29 Trail Geometry, SWAT™ Door integration, flip chip Head Tube/Bottom Bracket adjustment, threaded BB, fully enclosed internal cable routing, 12x5.8 inches dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 5.1 inches of travel
Fork
FOX FLOAT 34 Rhythm, GRIP damper, two position Sweep adjustment, 15x4.3 inches QR axle, 1.7 inches offset, 5.5 inches of travel
Rear Shock
FOX FLOAT DPS Performance, Rx Trail Tune, rebound and 3-position compression adjust, 190x45mm
Stem
Alloy Trail Stem, 1.4 inches bar bore
Saddle
Bridge Comp, Hollow Cr-mo rails, 155/143mm
Handlebars
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 1.2 inches rise, 30.7 inches width
SeatPost
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 3.9 inches, S2: 4.9 inches, S3: 5.9 inches, S4/S5: 6.7 inches, S6: 190mm
Grips
Specialized Trail Grips
Rear Brake
SRAM G2 RS, 4-piston caliper, hydraulic disk, 180mm
Front Brake
SRAM G2 RS, 4-piston caliper, hydraulic disk, 200mm
Bottom Bracket
SRAM DUB, BSA 2.9 inches, Threaded
Rear Derailleur
SRAM GX Eagle, 12-speed
Shift Levers
SRAM GX, trigger, 12-speed
Chain
SRAM NX Eagle, 12-speed
Crankset
SRAM X1 Eagle, DUB, 32T, S1: 6.5 inches, S2-S5: 6.7 inches, S6: 175mm
Cassette
Sram XG-1275, 12-speed, 10-52t
Chainrings
32T
Front Hub
Alloy, sealed cartridge bearings, 15x4.3 inches thru-axle, 28h
Front Tire
Butcher, GRID casing, GRIPTON® T9 compound, 29x2.3"
Spokes
DT Swiss Industry
Rear Tire
Purgatory, GRID casing, GRIPTON® T7 compound, 29x2.3"
Rear Hub
Alloy, sealed cartridge bearings, 148mmx0.5 inch thru-axle, 28h
Rims
Specialized 29, hookless alloy, 1.2 inches inner width, tubeless ready
Inner Tubes
Standard, Presta valve
Weight
30.6 lbs (30 lb, 8.9 oz)
Weight Size
S4
